Model Number

1042AHT

Screen Size

10.4 Inch with digital Panel

Resolution

800x600(support up to 1920x 1440)

Backlight

LED

Contrast Ratio

500:1

Aspect Ratio

4:3

Brightness

250cd/m²

Viewing Angle

70°/70°(L/R) ,50°/70(°U/D)

Input Voltage

DC12V±15%

Input Signal

 VGA,AV1,AV2,Audio,YPbPr,HDMI,DVI

HDMI Format

480i,480p,576i,576p,720p,1080i,1080p(50/60Hz)

Touch screen

4 Wire Resistive Touch ( 5 Wire resistive optional)

Touch Interface

USB for standard (RS 232 for optional)

Mounting Process

 Foldable Stand Bracket and VESA 75x75mm installing holes

Power Consumption

≦8W

Working Temperature

-20℃～60℃

Storage Temperature

-30℃～70℃

Unit Size

252L×216W×73H mm(folding)

252L×185W×267H mm(unfolding)

Unit Weight

1520g

OS Support for Touch

MAC,Vista,Linux ,Win CE, MS-DOS, Window XP, Window NT4

Window 9X/ME

Standard Accessories

AV Cable x 1,   VGA Cable x 1 , USB Cable X1 , Bracket x 1

Remote Controller x 1 , AC Adaptor x 1, Instruction Manual x 1

Touch Pen x 1 , Touch Driver Disc x 1 (for touch )

Packing Details

5PCS/CTN

N.W./G.W.: 17/18 KGS

Carton Size: 68x34x32cm
