Model Number

1042AHT

Screen Size

10.4 Inch with digital Panel

Resolution

800x600(support up to 1920x 1440)

Backlight

LED

Contrast Ratio

500:1

Aspect Ratio

4:3

Brightness

250cd/m²

Viewing Angle

70°/70°(L/R) ,50°/70(°U/D

Input Signal

 VGA,AV1,AV2,Audio,YPbPr,HDMI,DVI

Touch screen

4 Wire Resistive Touch ( 5 Wire resistive optional)

Touch Interface

USB for standard (RS 232 for optional)

Mounting Process

 Foldable Stand Bracket and VESA 75x75mminstalling holes

Power Consumption

≦8W

Storage Temperature

-30℃～70℃

Unit Weight

1520g

Model Number

101AHT

Screen Size

10.1 Inch with digital Panel

Resolution

1024x600(1366x768 optional) ,support up to 1920x 1440

Backlight

LED

Contrast Ratio

500:1

Aspect Ratio

16:9

Brightness

250cd/m²

Viewing Angle

70°/70°(L/R) , 40°/50(°U/D)

Input Voltage

DC12V±15%

Input Signal

VGA,AV1,AV2,Audio,YPbPr,HDMI(DVI optional)

HDMI Format

480i,480p,576i,576p,720p,1080i,1080p(50/60Hz)

Touch screen

4 Wire Resistive Touch ( 5 Wire resistive optional)

Touch Interface

USB for standard (RS 232 for optional)

Mounting Process

Foldable Stand Bracket and VESA 75*75mminstalling holes

Power Consumption

≦8W

WorkingTemperature

-20℃～60℃

Storage Temperature

-30℃～70℃

Unit Size

255Lx163Wx34.3H mm(folding)

255Lx163Wx60.3H mm(unfolding)

Unit Weight

1152g

OS Support for Touch

MAC,Vista,Linux ,Win CE, MS-DOS, Window XP, Window NT4

Window 9X/ME

Standard Accessories

SKS Cord  x 1,   VGA+USB Cable x 1 ,

Remote Controller x 1 , AC Adaptor x 1, Instruction Manual x 1

Touch Pen x 1 , Touch Driver Disc x 1 (for touch )

Packing Details

5PCS/CTN

N.W./G.W.: 16/17 KGS

Carton Size: 47.5x29.6x37 cm
